5 "안드로이드 휴대용 UHF RFID 리더 EM-Q51

• 지원 안드로이드 9.0 시스템 및 지원 UHF

• 옵션 3G/4G 모든 네트워크 통신, WiFi, 블루투스 및 기타 통신 모드

• 4000mAh 대용량 배터리가 장착 된이 기계는 9.5 시간의 내구성을 가지고 있습니다.

• MIL-STD-810G 따라 IP65 높은 보호 수준

• 지원 GPS, GLONASS, 더 정확한 위치

• 이미지 및 비디오 정보를 수집하기 쉬운 13 백만 픽셀 자동 초점 카메라 장착

• 지원 1D/2D, NFC 및 기타 기능 모듈 여러 산업의 응용 프로그램 요구를 충족

견적 받기 PDF 다운로드

emdoor 5 android handheld uhf rfid reader em q51

Android

Bluetooth

WiFi

3G/4G

IP65

GPS

Camera

NFC

5 "안드로이드 핸드 헬드 UHF RFID 리더 EM-Q51 6 조회

5'' Android: EM-Q51 Rugged Handheld

Specifications of 5'' Android handheld UHF RFID Reader EM-Q51

Basic parameters
Dimension	147.7 x 74 x 19mm
Weight	device unit 220g
Product Color	Black
LCD	5 inch IPS 16:9, 1280x720, 330nits
Touch Panel	5 point G+G capacitive touch screen Corning® Gorilla® Glass
I/O	TF Card x 1 SIM Card x 1 USB Type-C x 1 8Pin back shell x 1, 2Pin machine buttom x 1 Φ3.5mm standard earphone jack x 1
Power	AC100V ~ 240V, 50Hz/60Hz, Output DC 5V/2A
Camera	Rear 13MP
Performance parameter
CPU	ARM (OCTA Core), 2.0GHz
OS	Android 9.0
RAM	4GB
Storage	64GB
Data Collection
NFC	Built-in, ISO/IEC 14443A/B
1D	Support
2D	Support
Network connections
WIFI	WiFi 802.11 a/b/g/n/ac (2.4G+5G)
Bluetooth	BT4.0
3G/4G (Optional)	CMCC 4M： LTE B1/B3/B5/B7/B8/B20/B38/B39/B40/B41 WCDMA B1/B2/B5/B8 GSM B2/B3/B5/B8
GNSS	Built-in GPS+Glonass
Reliability
Operate Temperature	-10 °C ~ 55 °C
Store Temperature	-20 °C ~ 60 °C
Humidity	95% Non-Condensing
Rugged Feature	IP65 certified, MIL-STD-810G certified
Drop Height	1.2m
Battery
Capacity	3.85V/4000mAh
Type	Built-in Lithium-ion polymer battery
Endurance	9.5hrs (default 50% volumn，default 50% screen brightness， play 1080P HD video)

* Please be aware all technical data, specification and performance figures subject to change without notice.

Features of 5'' Android handheld UHF RFID Reader EM-Q51

1 Durability: The device is designed to withstand drops, shocks, and vibrations, with an IP65 rating for water and dust resistance.

2 Applications: The device can be used for inventory management, asset tracking, supply chain management, and other applications that require RFID technology. It supports various software development kits (SDKs) for application development.

3 The EM-Q51 handheld UHF RFID reader can be used in a variety of scenarios that require fast and accurate data collection, such as inventory management，asset tracking, supply chain management and retail.
